Reference: CM4
Brand: Line Audio
CARDIOID CONDENSER MICROPHONE Made in Sweden
Reference: 4010118474743
Brand: Beyerdynamic
DT-770 PRO 80 Ohm
Reference: 4010118459047
Brand: Beyerdynamic
DT 770 PRO, 250 ohms: for mixing applications in the stud
Reference: MOSC0033
Brand: Focusrite
The artist's 2-in, 2-out interface
Reference: ATH-M50 X
Brand: Audio-Technica
professional monitor headphones
Reference: LS 331 B
Brand: GRAVITY
Lighting Stand with Square Steel Base
Reference: GF310II
Brand: Yamaha
6 string acoustic guitar, dreadnought body model, colour: natural. Wood materials: spruce, nato/meranti, rosewood. The F310 offers the same focus on quality, design and sound as all Yamaha acoustics and puts it in an incredibly affordable package.
Reference: 4033653070331
Brand: Behringer
18-Channel, 12-Bus Digital Mixer for iPad/Android Tablets with 16 Programmable MIDAS Preamps, Integrated Wifi Module and Multi-Channel USB Audio Interface
Reference: iD4 MKII
Brand: Audient
2 IN / 2 OUT HIGH PERFORMANCE USB INTERFACE WITH SCROLL CONTROL
Reference: hs5
Brand: Yamaha
2-way bass-reflex bi-amplified nearfield studio monitor with 5" cone woofer and 1" dome tweeter.
Reference: 4033653170918
Brand: Behringer
Audiophile 18x20, 24-Bit/96 kHz USB Audio/MIDI Interface with MIDAS Mic Preamplifiers
Reference: 4010118459030
Brand: Beyerdynamic
Beyerdynamic DT 990 PRO Headphones
| Connections | |||
| SDI Inputs | 1 | SDI Audio Inputs | 16 channels embedded audio |
| SDI Loop Outputs | 1 | SDI Audio Outputs | 16 Ch embedded audio |
| SDI Video Outputs | 2 | HDMI Audio Inputs | 8 channels embedded audio |
| SDI Rates | SD, 1.5G, 3G, 6G and 12G | HDMI Audio Outputs | 8 channels embedded audio |
| HDMI 2.0 Video Inputs | 1 | Analog Audio Outputs | 1 x 6.35 mm headphone jack |
| HDMI 2.0 Video Outputs | 1 | Reference In | 1 |
| SMPTE ST-2110 IP Video Input/Output | 1 x 10G Ethernet | Reference Output | 1 |
| SMPTE ST 2110 IP Audio Inputs / Outputs | 16 channels embedded input and output audio on ST‑2110 IP video via 10G Ethernet | Ethernet | Ethernet supports 10/100/1000/10G BASE-T for SMPTE 2110 IP video in and out, configuration and software updates. |
| Audio | Front panel audio monitor speaker with speaker control button, plus 6.35 mm headphone socket. | Computer Interface | 1 x USB-C 3.0 for configuration and firmware updates |
| Video Standards | |||
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL | Color Precision | 8, 10 RGB 4:4:4 in all modes up to 1080p30 and 8, 10-bit YUV 4:2:2 in all modes |
| 2K Video Standards | 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 |
Color Space | Rec. 601, Rec. 709, Rec. 2020 |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 |
HDMI HD Video Standards | 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 |
| 4K Video Standards | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI | HDMI Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60 |
| SMPTE Compliance | SMPTE 259M, SMPTE 274M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2036‑1, SMPTE 2048‑1, SMPTE 2081‑10, SMPTE 2081‑11, SMPTE 2081‑12, SMPTE 2082‑10, SMPTE 2082‑11, SMPTE 2082‑12 and SMPTE ST2108‑1 | HDMI 4K Video Standards | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI |
| SDI Metadata Support | RP 188/SMPTE 12M-2 and closed captioning | HDMI Color Precision | 4:2:2 |
| Audio Sampling | Television standard sample rate of 48 kHz and 24 bit | HDMI Color Space | YUV |
| Audio | |||
| Local Audio Monitoring | Front panel audio monitor speaker with speaker control button, plus 6.35 mm headphone socket | ||
| IP Video Compliance | |||
| SMPTE 2110-20 (Uncompressed Video) | IGMP v2 | Precision Time Protocol | IEEE 1588-2008 (PTP v2)
ST 2059-1 ST 2059-2 |
| SMPTE 2110-21 (Traffic Shaping) | Sender: Narrow
Receiver: Narrow, Wide Synchronous, Asynchronous |
NMOS IS-04 Discovery and Registratio | v1.3.2
Peer-to-peer via mDNS/DNS‑SD |
| SMPTE 2110-30 (PCM) | Audio Conformance level: Level C | NMOS IS-05 Connection Managemen | v1.1.2 |
| SMPTE 2110-40 (Ancillary Data) | Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata | NMOS BCP-002-01 | Natural Grouping |
| Codec | Blackmagic IP10 codec used when converting 2160p59.94 and 2160p60 to 10G 2110 IP video | NMOS BCP-004-01 | Receiver capabilities |
| Control | |||
| Built in Control Panel | Built in control panel including 3 buttons, spin knob control and 2.2 inch color display | External Control | RJ-45 10Gb/s Ethernet and USB-C.
REST API over Ethernet for external control via HTTP when used with REST client applications |
| Displays | Built in 2.2 inch LCD for monitoring video, audio and status plus menu settings | ||
| Power Requirements | |||
| Power Supply | 1 x IEC C14 socket for AC power.
1 x 12V DC Input |
Power Usage | 30 W max. |
