Recording and playback, Video equipment, Control panels
| Connections | |||
| SDI Video Inputs | 1 | Reference Output | 1 x BNC Out
Tri-Sync or Black Burst |
| SDI Loop Outputs | 1 | SDI Audio Inputs | 64 channels embedded audio |
| SDI Video Outputs | 2 | SDI Audio Outputs | 64 channels embedded audio |
| SDI Monitor Outputs | 1 | HDMI Audio Inputs | 8 channels embedded audio |
| SDI Rates | 270Mb, 1.5G, 3G, 6G, 12G | HDMI Audio Outputs | 8 channels embedded audio |
| HDMI 2.0 Video Inputs | 1 | Remote Control | 1 x RS-422 In |
| HDMI 2.0 Video Outputs | 1 | Recorder Configuration | Via user interface on HDMI Out orBlackmagic HyperDeck Ethernet Protocol |
| HDMI Monitor Outputs | 1 | Ethernet | 1 x 10Gb/s RJ‑45 connector supporting 1000/10G BASE‑T |
| Built in Speaker | Mono | External Recording | 1 x USB-C 3.1 Gen 1 (up to 5Gb/s) for external disk recording |
| Audio Output | 1 x 6.35 mm headphone jack | Computer Interface | 1 x USB-C for software updates |
| Screen | 7 inch LCD | ||
| Reference Input | 1 x BNC In,
Tri-Sync/Black Burst and Timecode |
||
| Standards | |||
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL | Supported HDMI Formats | 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60, 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI |
| HD Video Standards | 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 |
Audio Sampling | Television standard 24‑bit, 48 kHz sample rate |
| 2K DCI Video Standards | 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI | Video Sampling | 4:2:2 YUV |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 | Color Precision | REC 601, REC 709, REC 2020.
33 point 3D LUTS can be applied to SDI monitor out |
| 4K DCI Video Standards | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI | HDR Support | Hybrid Log‑Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084 |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 424M | Multi Rate Support | Auto detection of SD, HD, 6G‑SDI and 12G‑SDI |
| SDI Metadata Support | Television standard 24‑bit, 48 kHz sample rate | Copy Protection | HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content |
| Media | |||
| Cache Recording | 2TB M.2 PCIe NVMe card for cache recording up to 16Gb/s included. Slot supports 60mm 80mm and 110mm cards. | Media Type | UHS-I and UHS-II SD cards |
| Media | 1 x SD card slot
1 x USB‑C 3.1 Gen 1 expansion port for external recording of SD, HD, 2K DCI, Ultra HD and 4K DCI |
Media Format
|
Can format media to ExFAT (Windows/Mac)or HFS+ (Mac) file systems |
| Supported Codecs | |||
| Video Codecs | ProRes HQ QuickTime, ProRes 422 QuickTime, ProRes LT QuickTime, ProRes Proxy QuickTime for all formats up to 2160p60.
Playback only of ProRes 4444 QuickTime up to 2160p60 with auto routing of fill and key over SDI A and B outputs. DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD formats up to 60fps. DNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p formats up to 60fps. H.265 High 4:2:0 10‑bit, H.265 Medium 4:2:0 10‑bit, H.265 Low 4:2:0 10‑bit for all 2160p formats up to 60 fps. H.264 SDI 4:2:2 10‑bit, H.264 High 4:2:0 8‑bit, H.264 Medium 4:2:0 8‑bit, H.264 Low 4:2:0 8‑bit for all formats up to 1080p60. |
Audio Codecs | AAC 2 Channels.
PCM 2, 4, 8, 16, 32 or 64 Channels
|
| Scopes | |||
| Scopes | Waveform, RGB Parade, Vector and Histogram scopes in broadcast quality 10-bit. | Viewing Modes | Picture in picture, picture overlay with opacity control. Waveform and RGB parade with standard and HDR graticules and Vector with zoom |
| Control | |||
| Built in Control Panel | Integrated capacitive touchscreen LCD with onscreen controls for settings and navigating menus. 11 buttons for transport and device control with search dial | External Control | 11 buttons for transport and device control with search dial |
| Teleprompter | |||
| Multi Rate Support | Outputs 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p defaulting to the highest rate | Supported File Formats | Rich text (.rtf) with support for most rich text formatting. Plain text (.txt) |
| Software | |||
| Software Included | Blackmagic OS
Blackmagic HyperDeck Setup |
Internal Software Upgrade | Loaded at system start, or via Blackmagic HyperDeck Setup using USB port |
| Displays | Built in LCD for video, audio and timecode monitoring and menu settings | ||
| Power Requirements |
